Frozen data structures meet constexpr

Serge « sans paille » Guelton <serge.guelton@telecom-bretagne.eu>

Cpp French User Group — Lutèce — mars 2018

sous l'influence de Chris Beck et Jérôme Dumesnil

About me

R&D engineer on compilation for security @ QuarksLab
Associate Researcher at Telecom Bretagne
Happy developer of Pythran
Soldier of Fortune

Foreword

All benchmarks are compiled using g++ -O2 -std=c++14

$ g++ --version
g++ (Debian 7.3.0-11) 7.3.0

All benchmarks are run on an Intel i7-6600U (i.e. my laptop) using Google benchamrk

About Perfect Minimal Hashing

perfect:
no collision
minimal
memory usage in O(n)

gperf implements that.

`const` is not `.rodata`

const std::set<int> nekrataal = { 1, 8, 7 };

$ objdump -S -Mintel -j .rodata a.o
...
0:  01 00 00 00 08 00 00 00 07 00 00 00

$ objdump -S -Mintel -j .text.startup a.o | wc -l
74

`constexpr` is the new `const`

With a constexpr constructor:

extern const frozen::set<int, 3> nekrataal = { 1, 8, 7 };

$ objdump -S -Mintel -j .rodata a.o
...
0:  00 00 00 00 01 00 00 00 07 00 00 00 08 00 00 00

$ objdump -S -Mintel -j .text.startup a.o | wc -l
objdump: section '.text.startup' mentioned in a -j option, \
    but not found in any input file

Use Case: string ⋄ enum

constexpr frozen::map<frozen::string, c_keyword, 32> Keywords{
    {"auto", KW_AUTO},
    {"break", KW_BREAK},
    ...
    {"volatile", KW_VOLATILE},
};

Use Case: Static Config

Date: Wed, 28 Mar 2018 15:21:51 +0000 From: Chris Beck <xxxxxxxxx> To: serge guelton <yyyyyyyy> Subject: Re: Frozen use at Tesla
Tesla autopilot uses shared memory segments (...).
At time of writing, we have an enum that describes all of the different shared memory segments used by different parts of the program, and a struct that describes the configuration of each segment – (...).
In the past we had a const std::map for this. Now we use a frozen::map, which simplifies the startup of the tasks.

Why? Shrink the binaries

enum style

.o size: 6072 bytes

char const * enum_to_string(RELOC_i386 e) {
  switch(e) {
    case RELOC_i386::R_386_NONE: return "NONE";
    case RELOC_i386::R_386_32: return "R32";
    ...

Why? Shrink the binaries

std::map style

.o size: 8496 bytes

const std::map<RELOC_i386, const char*> e2s = {
    { RELOC_i386::R_386_NONE,          "NONE"},
    { RELOC_i386::R_386_32,            "R32"},
    ...
};


char const * enum_to_string(RELOC_i386 e) {
  return e2s.at(e);
}

Why? Shrink the binaries

frozen::map style

.o size: 4088 bytes

constexpr frozen::map<RELOC_i386, const char*, 41> e2s = {
    { RELOC_i386::R_386_NONE,          "NONE"},
    { RELOC_i386::R_386_32,            "R32"},
    ...
};


char const * enum_to_string(RELOC_i386 e) {
  return e2s.at(e);
}

Why? Accelerate the binaries

Sucessively look for all elements in a set of 32 integers:

------------------------------------------------------------------
Benchmark                           Time           CPU Iterations
------------------------------------------------------------------
BM_IntInFzSet                    1672 ns       1672 ns     417271
BM_IntInStdSet                   5748 ns       5747 ns     119478
BM_IntInStdArray                 2749 ns       2749 ns     254695

Why? Accelerate the binaries

Sucessively look for elements not in a set of 32 integers:

------------------------------------------------------------------
Benchmark                           Time           CPU Iterations
------------------------------------------------------------------
BM_IntNotInFzSet                 1668 ns       1667 ns     417931
BM_IntNotInStdSet                5899 ns       5899 ns     115567
BM_IntNotInStdArray              3645 ns       3643 ns     192033

Why? Accelerate the binaries

Sucessively look for elements in a unordered_set of 32 strings:

------------------------------------------------------------------
Benchmark                           Time           CPU Iterations
------------------------------------------------------------------
BM_StrInFzUnorderedSet           2583 ns       2583 ns     268092
BM_StrInStdUnorderedSet          4802 ns       4800 ns     145135
BM_StrInStdArray                 4829 ns       4829 ns     146107

Why? Accelerate the binaries

Sucessively look for elements not in an unordered_set of 32 strings:

------------------------------------------------------------------
Benchmark                           Time           CPU Iterations
------------------------------------------------------------------
BM_StrInFzUnorderedSet           2583 ns       2583 ns     268092
BM_StrInStdUnorderedSet          4802 ns       4800 ns     145135
BM_StrInStdArray                 4829 ns       4829 ns     146107

Compile Time Binary Search

#include <frozen/set.h>
constexpr frozen::set<unsigned, 15> primes = {
    2, 3, 5, 7,
    11, 13, 17, 19,
    23, 29, 31, 37,
    41, 43, 47};

bool is_small_prime(int n) {
  return primes.count(n);
}

Compile Time Binary Search: Assembly

Compiler with clang for (almost) branchless code

$ clang a.c -O2 -std=c++14 -c
$ objdump -S -Mintel -j .text a.o

0000000000000000 <_Z14is_small_primei>:
   0:       83 ff 13                cmp    $0x13,%edi
   3:       b8 00 00 00 00          mov    $0x0,%eax
   8:       b9 00 00 00 00          mov    $0x0,%ecx
   d:       48 0f 47 c8             cmova  %rax,%rcx
  11:       39 79 0c                cmp    %edi,0xc(%rcx)
  14:       48 8d 41 10             lea    0x10(%rcx),%rax
  18:       48 0f 43 c1             cmovae %rcx,%rax
  1c:       39 78 04                cmp    %edi,0x4(%rax)
  1f:       48 8d 48 08             lea    0x8(%rax),%rcx
  23:       48 0f 43 c8             cmovae %rax,%rcx
  27:       39 39                   cmp    %edi,(%rcx)
  29:       48 8d 41 04             lea    0x4(%rcx),%rax
  2d:       48 0f 43 c1             cmovae %rcx,%rax
  31:       b9 00 00 00 00          mov    $0x0,%ecx
  36:       48 39 c8                cmp    %rcx,%rax
  39:       74 06                   je     41 <_Z14is_small_primei+0x41>
  3b:       39 38                   cmp    %edi,(%rax)
  3d:       0f 96 c0                setbe  %al
  40:       c3                      retq
  41:       31 c0                   xor    %eax,%eax
  43:       c3                      retq

Compile Time Hashing, aka `gperf`

Read the original blog post by Steve Hanov
Choose a dummy hash function

Parametrize it by a random parameter, eg

constexpr std::size_t
operator()(string value, std::size_t seed) const {
  std::size_t d = seed;
  for (std::size_t i = 0; i < value.size(); ++i)
    d = (d * 0x01000193) ^ value[i];
  return d;
}

Compile Time Hashing, aka `gperf`

Starting with the buckets with more collisions, iteratively look for a seed that generates no collision in the final table
Store this seed in the intermediate table, and process next bucket

Sounds too random? there's a paper that states it's in O(n) :-)

Bonus: Use Frozen in a meta program

All methods calls are constexpr thus...

#include <frozen/set.h>

static constexpr frozen::set<unsigned, 3>
supported_sizes = {
  1, 2, 4
};

static_assert(supported_sizes.count(sizeof(long)),
              "unsupported size");

Bonus: Compile Time initialization of string search

From c++17

std::search(in.begin(), in.end(),
            std::boyer_moore_searcher(needle.begin(),
                                      needle.end())

Make the init phase constexpr!

std::string haystack = "ABC ABCDAB ABCDABCDABDE";
auto index = frozen::search(
    haystack.begin(), haystack.end(),
    frozen::make_boyer_moore_searcher("ABCDABD")
);

Frozen in LIEF

LIEF - Library to Instrument Executable Formats https://lief.quarkslab.com

Uses Frozen for fast and efficient storage of enums
Plan to use Frozen for fast strstr

Frozen @ Tesla

Contributor to the project!

Uses frozen for

Various enum interactions
Static configuration storage
Avoid SIOF

Frozen @ home

Store a colormap:

constexpr frozen::map<char, std::array<char, 3>, 5> ColorMap{
    {'R', {(char)0xFF, (char)0x00, (char)0x00}},
    {'G', {(char)0x00, (char)0xFF, (char)0x00}},
    {'B', {(char)0x00, (char)0x00, (char)0xFF}},
    {'#', {(char)0x00, (char)0x00, (char)0x00}},
    {' ', {(char)0xFF, (char)0xFF, (char)0xFF}},
}

Frozen @ home

And use it to turn ASCIIART into PPM at compile time

constexpr unsigned char bytes[] =
    "      ######      "
    "    ##GGGG  ##    "
    "   #  GGGG    #   "
    "  #  GGGGGG    #  "
    "  # GG    GG   #  "
    " #GGG      GGGGG# "
    " #GGG      GG  G# "
    " # GG      G    # "
    " #  GG    GG    # "
    " #  GGGGGGGGG  G# "
    " # GG########GGG# "
    "  ###  #  #  ###  "
    "   #   #  #   #   "
    "   #          #   "
    "    #        #    "
    "     ########     "
};

Credits

Thanks to Quarkslab for allowing me to sped time on that project.

Kudos to Chris Beck and Jérôme Dumesnil for the common work!

$ lynx https://github.com/serge-sans-paille/frozen
